Structural Engineering Service

VRR has one of the largest trained steel detailing teams. We are not only experienced in 3D and 2D detailing software but also in steel detailing of all kind of steel structures per the fabricator’s and erector’s need. Our detailing team of engineers and drafts personnel’s have good knowledge of AISC (American Institute of Steel Construction), BS (British Standard codes for steel detailing), OSHA rules, NISD (National Institute of Steel Detailing). We are doing imperial and matric units.

As a new client we will discount the 50% of cost of the first job.

Shop Drawings

For our esteemed clients, we are offering an enormous range of Shop Drawings. We are committed to producing the highest quality detailing and production of fabrication shop drawings and erection drawings in accordance various international standards such as AISC, BS, IS code and OSHA and provide the drawings in .dwg, .dxf, .pdf and various different formats. The provided services are rendered in line with the industry standards by our proficient professionals. Our offered services are widely appreciated in the market for its promptness and reliability.

Other details:

Tailor made
Highly reliable
More trustworthy

Design of Structural Steel Pipe Racks

Pipe Racks

Pipe racks or pipe bridges are structures designed and built specifically to support multiple pipes where adequate structure is not available. Pipe layout on pipe racks should follow the Pipe Planning Study concepts, which established in the preliminary engineering phase of a project.

Pipe racks are necessary for arranging the process and service pipelines throughout the plant. A large number of process pipelines, flare lines and manifold lines running through this racks from one equipment to another, or from one unit to another.

structural Design And Detail Engineering

Service Details:

Build Up Area / Size Any

Site Location Any

Mission Statement:

Various kinds of Civil Engineering Services are being offered by us as per world-class standards. These are basically technical services to meet the technical and managerial functions of the diverse industries. This is a service-oriented department, which provides high-end engineering expertise to the customer.

Features:

Equipment and machinery foundations
Large diameter storage tank foundations
All kind of pressure vessel foundation design
Retaining, dyke, and boundary walls
Cable and pipe trenches and tunnels
Gates, compound walls, and fencing
Civil Foundation layout with RCC details

Steel Structural Drafting and Detailing

Service Details:

Minimum Order Quantity 1 Ton

Build Up Area / Size 1

Site Location ANY

We are the leading service provider of Steel Structural Drafting and Detailing. Our experienced professionals are well-versed in rendering these drafting services as per the demands of our client. We use advanced technology to offer these drafting services in compliance with industry norms. Apart from this, these drafting services are offered to our customers at pocket friendly prices.

Other details:

Generation of Structural single and assembly drawings
Generation of Bill of Material (BOM), Bill of Quantity (BOQ) & MTO (Material Take Off)
Support arrangements drawings
Structural Pipe rack detail engineering

Other Information’s:

Generation of Structural single and assembly drawings
Generation of Bill of Material (BOM), Bill of Quantity (BOQ) & MTO (Material Take Off)
Support arrangements drawings.
Structural Pipe rack detail engineering
Preparation of Layouts and Details for Conveyor gantries.
Preparation of Layouts and Details for Hoppers, Bunkers with supporting structures, Silo Roof (Steel) for large storage silos and general steel structures.
Preparation of fabrication and shop drawings for structural
Preparation of Detail and As-built arrangements drawings
Preparation of Steel support arrangements drawings
Preparation of Steel General Arrangement (GA) drawings
Generation of Structural Isometrics
Design of Structural steel chimneys
Pre-Engineering Building design
Steel connection analysis
Steel connection drawing with BOM
Taking of steel structural Bill of material, Bill of quantity and Material take off.
